Whipple 11-23 MUSTANG 5.0/5.2L 10-Rib Belt System
WB-COY10-5BLT
2018-2023 FORD MUSTANG COYOTE
WHIPPLE 10-RIB RACE BELT SYSTEM
As power levels increase, belt control becomes one of the most important parts of a reliable high-horsepower supercharger combination. Whipple developed this race-proven 10-rib belt system upgrade for customers looking to improve grip, stability, and confidence in demanding 2018-2023 Mustang Coyote applications.
The WB-COY10-5BLT is designed for 2018-2023 Ford Mustang Whipple applications and is built around the ATI balancer platform. This upgrade package is engineered to support both stock diameter and 20% overdrive ATI balancer combinations while delivering a stronger, more durable belt-drive solution for serious high-performance use.
The system includes a heavy-duty Whipple billet tensioner, adjustable idler, billet 10-rib smooth idlers, billet 10-rib grooved alternator pulley, 10-rib water pump pulley, and Gates belt. Together, these components create a more robust drive system for customers pushing their Whipple combinations harder on the street, strip, or other demanding performance environments.
The installation manual also includes pulley, belt-length, and boost-reference charts for stock balancer and 20% overdrive configurations, with separate guidance for 132mm throttle body and stock throttle body combinations. That makes this system especially useful for serious builds where matching pulley ratio, belt length, and airflow combination matters.
Key Features:
- 10-rib belt system upgrade for 2018-2023 Ford Mustang Whipple applications
- Built for improved belt control and reliability in high-horsepower combinations
- Designed to work with ATI balancers in stock diameter or 20% overdrive configurations
- Includes heavy-duty Whipple billet tensioner
- Includes adjustable idler assembly
- Includes billet 10-rib smooth idlers
- Includes billet 10-rib grooved alternator pulley
- Includes 10-rib water pump pulley
- Includes Gates belt
- Supports higher-boost Whipple combinations with stronger belt-drive control
- Pulley / belt / boost charts included in the installation manual for stock and 20% ATI balancer combinations
- Installation of the 10-rib system voids any Whipple powertrain warranty
Application Notes:
- Designed around ATI hub and ATI balancer fitment
- Manual includes separate pulley / boost guidance for 132mm throttle body and stock throttle body combinations
- Belt length selection varies by supercharger pulley size and balancer configuration
- For Whipple-equipped high-performance applications where stronger belt-drive control is required
Original: $2,515.06
-65%$2,515.06
$880.27Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
WB-COY10-5BLT
2018-2023 FORD MUSTANG COYOTE
WHIPPLE 10-RIB RACE BELT SYSTEM
As power levels increase, belt control becomes one of the most important parts of a reliable high-horsepower supercharger combination. Whipple developed this race-proven 10-rib belt system upgrade for customers looking to improve grip, stability, and confidence in demanding 2018-2023 Mustang Coyote applications.
The WB-COY10-5BLT is designed for 2018-2023 Ford Mustang Whipple applications and is built around the ATI balancer platform. This upgrade package is engineered to support both stock diameter and 20% overdrive ATI balancer combinations while delivering a stronger, more durable belt-drive solution for serious high-performance use.
The system includes a heavy-duty Whipple billet tensioner, adjustable idler, billet 10-rib smooth idlers, billet 10-rib grooved alternator pulley, 10-rib water pump pulley, and Gates belt. Together, these components create a more robust drive system for customers pushing their Whipple combinations harder on the street, strip, or other demanding performance environments.
The installation manual also includes pulley, belt-length, and boost-reference charts for stock balancer and 20% overdrive configurations, with separate guidance for 132mm throttle body and stock throttle body combinations. That makes this system especially useful for serious builds where matching pulley ratio, belt length, and airflow combination matters.
Key Features:
- 10-rib belt system upgrade for 2018-2023 Ford Mustang Whipple applications
- Built for improved belt control and reliability in high-horsepower combinations
- Designed to work with ATI balancers in stock diameter or 20% overdrive configurations
- Includes heavy-duty Whipple billet tensioner
- Includes adjustable idler assembly
- Includes billet 10-rib smooth idlers
- Includes billet 10-rib grooved alternator pulley
- Includes 10-rib water pump pulley
- Includes Gates belt
- Supports higher-boost Whipple combinations with stronger belt-drive control
- Pulley / belt / boost charts included in the installation manual for stock and 20% ATI balancer combinations
- Installation of the 10-rib system voids any Whipple powertrain warranty
Application Notes:
- Designed around ATI hub and ATI balancer fitment
- Manual includes separate pulley / boost guidance for 132mm throttle body and stock throttle body combinations
- Belt length selection varies by supercharger pulley size and balancer configuration
- For Whipple-equipped high-performance applications where stronger belt-drive control is required
